TWPro Silver – Storm Collar w/ Silicone Seal- Ø 125

Description

The TWPro Silver – Storm Collar w/ Silicone Seal- Ø 125 is designed to ensure watertightness during the passage through the roof, providing protection for the flashing in extreme weather conditions.

It should be installed approximately 25mm above the highest part of the flashing.

It comes with a Silicone Seal to provide a watertight seal around the pipe.

Product Information

Application: Intended for use with solid fuel and gas/oil appliances, including woodstoves, gas coal effect fires, oil and gas boilers, and any solid fuel appliances.
Construction:

• Outer Skin: constructed from 304-grade Stainless Steel with a thickness of 0.4mm.
• Inner Skin: constructed from 316-grade Stainless Steel with a thickness of 0.4mm.
• Insulation: comprised of compressed rockwool with a density of 200kg/m³ for TWPro / 128kg/m³.
• Welding All parts are meticulously welded.

Safety: A minimum 50mm distance to combustibles is required for TWPro and a minimum 60mm for KC.
Approvals: TWPro is HETAS Approved and CE marked.

Designation Numbers:

• TWPro EN1856-1 T600 N1 W V2 L50040 G50
• TWPro EN1856-1 T200 W V2 L50040 O20
• KC EN1856-1 T600 N1 W V2 L50040 G60
• KC EN1856-1 T200 W V2 L50040 O20

Installation: TWPro Insulated Chimney Parts are secured together using a Locking Band.

Please maintain the required safe distance to the outside of the flue to any combustible material, such as wood or plasterboard.

Choose TWPro for a dependable and efficient solution to enhance your chimney system’s performance.
